GatesAir PTR-255 Program Audio Codec Module
Intraplex Products Issue 2.1, February 2006
!!! IMPORTANT: The module must be inserted so that the white ejector tab is at the bottom
in a 3RU shelf and at the right in a 1RU shelf.
6.2.2 Configuration Procedure Using IntraGuide
1. Set the module for remote operation by setting the REMOTE switch down.
2. Insert the module into the selected slot in the multiplexer shelf, making sure it is the slot
which mates with the MA-555 (or the audio connector side of the MA-556).
!!! IMPORTANT: The module must be inserted so that the white ejector tab is at the bottom
in a 3RU shelf and at the right in a 1RU shelf.
3. Connect a PC to the remote port on the multiplexer and start the IntraGuideā¢
configuration program.
4. Set the parameters for the card as shown on the IntraGuide screen. Consult the
IntraGuide on-line help facility for details.
