GatesAir PTR-255 Program Audio Codec Module
Intraplex Products Issue 2.1, February 2006
10
Table 2-2
AES/EBU Channel Status (C) Data: Professional Format
Byte
Bit
Function
RX
TX
Remarks
4-7 user bit
mode
0000 not ind
0001 192 bit
0010 AES18
0011 user def.
0100 to 1111
N
N
N
N
N
Y
N
N
N
N
2
0-2
aux bit usage
000 not ind
001 audio data
010 co-ord
011 to 111
N
N
N
N
Y
N
N
N
3-5 sample
length
000 not ind
100 16 bits
all other states
N
N
N
N
Y
N
RX accepts 16 bit words; TX
sends 16 bit words
6-7
reserved
00
N
Y
TX Validity bit handling:
 When in 2 channel mode, any unmitigated A channel error mutes the A channel
outgoing audio and sets the A channel validity bit to 1; any unmitigated B channel
error mutes the B channel outgoing audio and sets the B channel validity bit to 1.
 When in 1 channel mode, any unmitigated A channel error mutes the A channel
outgoing audio and sets the A channel validity bit to 1. The B channel validity bit is
always set to 0.
RX Validity bit and error handling: both outputs of the PTR-255 are muted if any of these occur:
 Loss of PLL lock
 Parity error
 Biphase error
 When in 2 channel mode and A channel validity bit = 1 or B channel validity bit = 1
 When in 1 channel mode and A channel validity bit = 1
Audio sampling rates supported: Output: 32, 48 ksps; Input: 32, 44.1 and 48 ksps.
