Table 3-9
Gain Switch Settings
Switch
Setting
Input Sensitivity (TX Gain),
or Maximum Output Level (RX Gain) in dBu
0
+9
1
+10
2
+11
3
+12
4
+13
5
+14
6
+15
7
+16
8
+17
9
+18
A
+19
B
+20 (factory default setting)
C
+21
D
+22
E
+23
F
+24
