GatesAir PTR-255 Program Audio Codec Module
Intraplex Products Issue 2.1, February 2006
47
Connector
DB-15 on MA-556
Physical and Environmental:
Temperature
0 to 50°C Operating
Humidity
0 to 90%, Non-condensing
Power Consumption
Varies by power rail and module adapter, as shown below
Module Configuration
+5V rail
+15V rail
-15V rail
Total:
PTR-255 w/MA-555
4.75W
1.5 W
1.1 W
7.35 W
PTR-255 w/MA-556
(typical)
5.1 W
1.5 W
1.1 W
7.7 W
PTR-255 w/MA-556
(with maximum user draw)
6.25 W
1.5 W
1.1 W
8.85 W
Regulatory Compliance
FCC part 15 Class A
CE compliant (EMC Directive 89/336/EEC)
VCCI Class 1
Austel AS3548 Class A
Specifications Subject To Change Without Notice.
