GatesAir PTR-255 Program Audio Codec Module
Intraplex Products Issue 2.1, February 2006
A-5
A.2 S Codes
S codes appear in response to an ISiCL STATUS? query. There is one active S code for the PTR-
255, as defined in Table A-2. S05 is used to display the software version but S02, S03 and S04
are not used.
Table A-2
PTR-255 Remote Status Messages (S Codes)
S Code
Digit
Description
ALARM
---
When present, indicates hardware failure.
S01
B00000000
-----
Not used.
B00000000
-------
Receive sync indicator.
0 = Audio receiver not in sync
1 = Audio receiver in sync
B00000000
-------
Configuration error.
0 = Normal
1 = Configuration error detected (module will not operate)
B00000000
-------
Backplane clock frequency.
0 = 1.544 MHz clock detected (normal in an T1, VRM or ISDN
multiplexer)
1 = 2.048 MHz clock detected (normal in an E1 multiplexer)
B00000000
-------
Transmit lock indicator.
0 = Transmitter not sending data
1 = Transmitter sending data
S02
B00000000

Not used.
S03
B00000000

Not used.
S04
B00000000

Not used.
S05
B00000000

Displays the Software Version
