167
Gateway 4-bay Small Form Factor case
www.gateway.com
8 Reconnect the drive cables using your notes from Step 3. The red-striped
edge of the data ribbon cable indicates Pin 1 and corresponds with Pin 1
on the drive (typically on the side farthest from the power supply
connection). See the drive documentation for further instructions.
9 Close the case by following the instructions in “Closing the case” on
page 161.
Adding or replacing a 3.5-inch drive in the
expansion bay
Use these instructions to add or replace a 3.5-inch drive in the expansion bay.
To add or replace a 3.5-inch drive in the expansion bay:
1 Identify your computer case style. For more information, see “Identifying
your computer case style” on page 106.
2 Open the case by following the instructions in “Opening the case” on
page 158.
