90
Chapter 3
Removing the Inverter Board
1.
See “Removing the LCD Assembly” on page 85.
2.
Remove the adhesive tape from the i
nverter cables.
3.
Remove one (1) screw from the
inverter board.
4.
Using both hands, rotate the in
verter board around
the hook to fre
e it from the panel.
Ste
p
Size
Quantity
Screw T
ype
Inverter Board
M2.5*5
1
