Chapter 3 83
Removing the CPU
IMPORTANT: The pins on the underside of the CPU are very delicate. If they are damaged, the CPU may
malfunction. Place the CPU on a clean, dry surface when it is not installed.
1. See “Removing the Thermal Module” on page 81.
2. Using a flat-bladed screw driver, rotate the CPU locking screw 180° clockwise as shown.
3. Lift the CPU clear of the socket as shown.
To Next Page
