Chapter 3
81
Removing the Thermal Module
1.
See “Removing the Upper Co
ver” on page 62.
2.
See “Removing the Mainboard” on page 77.
3.
Disconnect the fan cable.
4.
Remove the four (4) securing screws (in reverse numeri
cal orde
r from screw 4 to screw 1) from the Thermal
Module.
Ste
p
Size
Quantity
Screw T
ype
Thermal Module
M1.98*3.0
4
1
2
3
4
90
92
