74 Chapter 3
Removing the USB Board
1. See “Removing the Upper Cover” on page 62.
2. Unlock the mainboard to USB cable connector.
3. Remove the cable from the chassis by pulling up on the adhesive.
4. Remove one (1) screw from the USB board.
Step Size Quantity Screw Type
USB M2*3 1
