94
Chapter 3
Removing the LCD Brackets and FPC Cable
1.
See “Removing the LCD Panel” on page 92.
2.
Remove the six (6) securing screws (three on each side) from the LCD Panel brackets.
3.
Remove the LCD brackets from the LCD Panel.
4.
Peel back the mylar securin
g the L
VDS cable.
Ste
p
Size
Quantity
Screw T
ype
LCD Brackets
M2*3
6
