Gateway NV59C Series - LCD Assembly

168 Chapter 6
LCD Assembly
No. Description Acer P/N No. Description Acer P/N
1 LCD Bezel 60.WJ802.004 6 LCD Panel LK.15605.010
2 LCD Bracket (L) 33.WJ802.004 7 LVDS Cable 50.WJ802.006
3 Antenna Cable
(Main)
50.WJ802.004 8 Antenna Cable
(Aux)
50.WJ802.005
4 Microphone Cable 23.WJ802.001 9 Camera Module 57.WJ802.001
5 LCD Bracket (R) 33.WJ802.004 10 LCD Cover 60.BHN02.001
1
2
3
4
5
6
7
8
9
10
