Chapter 3 135
Replacing the ODD Module
1. Press the bezel into the tray, bottom edge first, to
secure it to the ODD Module.
2. Place the bracket on the ODD module.
3. Secure the ODD bracket with the two (2) screws.
4. Push the ODD Module into the ODD bay until it is
flush with the casing.
5. Replace the one (1) screw to secure the Module.
