Chapter 3 69
Removing the Power Board
1. See “Removing the Upper Cover” on page 62.
2. Turn the upper cover over. Pass the cable through the upper cover as shown.
3. Remove two (2) screws from the power board.
4. Remove the power board assembly and lift the power board clear of the device.
Step Size Quantity Screw Type
Power board M2*3 2
