Gateway NV59C Series - Removing the Left Speaker Module

66 Chapter 3
Removing the Left Speaker Module
1. See “Removing the Upper Cover” on page 62.
2. Locate the Left Speaker Module on the Upper Cover as shown.
3. Remove two (2) screws from the left speaker module.
4. Lift the Speaker clear of the Upper Cover. Ensure that the cable is free from all cable clips.
Step Size Quantity Screw Type
Left Speaker
Module
M2*3 2
