Gateway NV59C Series User Manual

160 Chapter 5
Bottom View
Item Description Item Description
PJP2 Connect to Battery JHP1 Connect to external headphone
PJP1 DC-IN jack JBT1 Connect to BT
JDIMM1/
JDIMM2
DDR3 memory socket JHDD1 Connect to SATAHDD
JCRT1 Connect to external CRT JODD1 Connect to SATAODD
JRJ45 RJ45 LAN JP4 Connect to 3G board
JHDMI1 HDMI connector JFAN1 Connect to FAN
JMINI1 Connect to WLAN JCPU1 CPU socket
JUSB1 USB connector U41 PCH
JMIC1 Connect to external microphone
