Chapter 3 67
Removing the Right Speaker Module
1. See “Removing the Upper Cover” on page 62.
2. Locate the Right Speaker Module on the Upper Cover as shown.
3. Remove the one (1) securing screw from the Right Speaker Module.
4. Remove the Right Speaker Module cable from the cable channel. Ensure that the cable is free from all cable
clips.
Step Size Quantity Screw Type
Right Speaker
Module
M2*3 1
To Next Page
