54 Chapter 3
Removing the WLAN Module
1. See “Removing the HDD/WLAN/DIMM Door” on page 50.
2. Disconnect the two (2) antenna cables from the WLAN Board.
3. Move the antenna away and remove the one (1) screw to release the WLAN Board.
Step Size Quantity Screw Type
WLAN Module M2*3 1
