Gateway NV59C Series - LCD Module Disassembly Process; LCD Module Disassembly Flowchart

84 Chapter 3
LCD Module Disassembly Process
LCD Module Disassembly Flowchart
Screw List
Step Screw Quantity Part No.
LCD Bezel M2.5*6 2 86.WJ802.003
LCD Panel M2.5*6 2 86.WJ802.003
LCD Brackets M2*3 6 86.WJ802.004
Inverter Board M2.5*5 1 86.WJ802.001
LCD Assembly M2.5*8 4 86.WJ802.002
Remove LCD
Assembly
Remove
Camera Module
Remove
LCD Bezel
Remove
LCD Panel
Remove
LCD Brackets
and FPC Cable
Remove
Antennas
Remove
Microphone
Cable
Remove
Inverter Board
