158 Chapter 4
InsydeH2ODDT Debugger POST Code Table
SMM_ACPI_DISABLE_START SMM 0xA8 OS call ACPI disable function
SMM_ACPI_DISABLE_END SMM 0xA9 ACPI disable function complete
Functionality Name
(Include\ PostCode.h)
PostCode Description
Used by Insyde debugger 0x0D Waiting for device connect
Used by Insyde debugger 0xD0 Waiting for device connect
Used by Insyde debugger 0xD1 InsydeH2ODDT Ready
Used by Insyde debugger 0xD2 EHCI not found
Used by Insyde debugger 0xD3 Debug port connect low speed device
Used by Insyde debugger 0xD4 DDT Cable become low speed device
Used by Insyde debugger 0xD5 DDT Cable Transmission Error (Get descriptor fail)
Used by Insyde debugger 0xD6 DDT Cable Transmission Error (Set Debug mode fail)
Used by Insyde debugger 0xD7 DDT Cable Transmission Error (Set address fail)
Functionality Name (Include\
PostCode.h)
Phase
Post
Code
Description
