18 Chapter 1
Onboard LAN
Feature Support for 10/100/1000
Item Specification
Manufacturer Broadcom 57780KMLG for GIGA LAN
• Integrated 10/100/10000BASE-T transceiver
• Automatic MDI crossover function
• PCIe V1.1 compliant
• 10/100/10000BASE-T full -duplex/half -duplex MAC
• Receive side scaling (RSS) for multicore processors
• Complies with IEEE 802.3, 802.3u, 802.3ab, and
802.1p
• Wake on LAN (WOL) support meeting the ACPI
requirements
• Statistics for SNMP MIB II, Ethernet-like MIB, and
Ethernet MIB (IEEE 802.3z, Clause 30)
• Self-boot feature, utilizing smaller EEPROM size with
ability to use on-chip memory
• Supports iSCSI boott
• PCI Express CLKREQ support
• Integrated switching regulator for improved power
consumption
• IPv4 and IPv6 large send offload and checksum
offload(LSO/TCO)
Item Specification
