22 Chapter 1
LCD 15.6”
Card Reader
Item Specification
Vendor/model name AUO/CPT/CMO/Samsung/LCD/INL
Screen Diagonal (mm) 15.6 inches
Display resolution (pixels) 1366 x 768 WXGA Clare
Pixel Pitch 0.204 x 0.204
Display Mode Normal
Typical White Luminance (cd/m
2
)
(also called Brightness)
220
Contrast Ratio 500 typical
Response Time (Optical Rise
Time/Fall Time) msec
8
Luminance Uniformity 1.25 max
Electrical Interface LVDS
Support Color 262K
Viewing Angle (up/down/right/
left)
15/35/45/45
Temperature Range (°C)
Operating
Storage (shipping)
0 to +50
-20 to +60
Item Specification
Part Name RealTek 5160
Package 5-in-1 card reader
General Features • PCI-E interface
• Push-push type
•Dummy card
