Chapter 3 79
6. Carefully turn the mainboard over and place it on a clean, dust-free surface.
7. Disconnect the power cable.
8. Remove the mainboard from the chassis and turn it over.
NOTE: Circuit boards >10 cm² have been highlighted with a yellow rectangle as shown in the
previous image. Please detach the Circuit board and follow local regulations for disposal.
