GA600AC Sliding Gate Opener User Manual
15
J5 Terminal
Hall Sensor
J3 Terminal
Learn Button
J6 Terminal
Dip Switches
Potentiometers
Control Board
Programming and Wiring
Any works to the 110V/220V AC must only be performed by a licensed electrician.
Ensure power is off before any modifications are made.
Figure 14
Fuse
(10A 250V fuse)
J2 Terminal
J1 Terminal
J4 Terminal
