J1 Terminal
PE: Earth (yellow/green wire).
L: Power (brown wire).
N: Power (blue wire).
J2 Terminal
MOT1: Motor Terminal, swap with MOT2 to change gate
moving direction.
MOT2: Motor Terminal, swap with MOT1 to change gate
moving direction.
MOTCOM: Motor Common Terminal.
LAMP (L&N): Connection for warning lamp.
PE: Motor and warning lamp earth
Note: If require to change the moving direction, not
only MOT1 and MOT2 wires need to be swapped, but
also the wires of 11 and 13 on J5 Terminal have to be
swapped with each other.
J3 Terminal
Motor Capacitor
