GA600AC Sliding Gate Opener User Manual
4
Technical Parameters
Model
GA600AC
Power Supply
220VAC/50Hz 110VAC/60Hz
Motor Power
280W
Weight
10.5kg
Overall Dimensions (L×W×H)
267×219×285mm
Gate Moving Speed
12m/min
Maximum Loading Weight
600kg
Remote Control Distance
≥ 30m
Remote Control Mode
Single button mode / Three button mode
Limit Switch
Spring limit switch / Magnetic limit switch
Working Noise
≤ 56dB
Working Duty
S2, 20min
Working Temperature
-20°C ~ +70°C
Recording of up Remote Controls
25
Remote Frequency
433.92 MHz
Installation
Before You Start
· GA600AC Sliding Gate Automation Kit is suitable for powering the opening and closing motion
of gates up to 600kg in weight, up to a length of 8m.
· Gate motion is achieved by the rotating output gear of the gate opener driving the gear rack
(sold separately) fitted to the moving gate.
· The gate opener requires you to press the remote control once to open, and once again to
close. This is a safety feature to ensure safe operation.
· The opener must be fitted within private property, never externally to a property’s boundary.
Any works done to the gate opener must be completed whilst the power is off and the
opener is unplugged. Any modifications/alterations/works to AC power components must
only be completed by a licensed electrician.
Tools Required
· Tape measure
· Level
· 12mm concrete drill and hammer (when uses expansion screws)
· Phillips head screwdriver
· Straight screwdriver
