Clutch Bell assembly-3
Engine fan assembly
ᚕӬᏣဌಣ၇.4
ය৵ಣ၇
6
ᆅ២O྄්α
ᆅ២T྄්α
M3x6 4pcs
M3x6........................x4
஡ಣಣ၇ԂٯٻңݗК஡ᖴҕᚈߤܼЖᔞαȄ
ٻңBCጳᘈӬᆅ២ȂЎ໕༰ܢܼю዁ϲӕ஡ᆅ២ᆨஞᔇΤȄ
Assemble the engine fan and tighten the hex nut.
Use AB glue to fix the two magnets onto fan surface.
Put AB glue in the circular groove on the fan, then insert the magnets.
It is important to put one magnet with the north pole facing up and the other
magnet with the south pole facing up.
Magnet with south
magnetic pole facing up.
Magnet with north
magnetic pole facing up.
M3x6
M3x6
M3x6
M3x6........................x3
ᖴ๜ְሰαЦྥᏙ
All screws on side plates should
be applied with thread lock.
ᖴ๜ְሰαЦྥᏙ
All screws should be applied with
thread lock.
(9x14x1)
Stock Engine Washer
provided by OS
將引擎內附華司(9x14x1)
放入引擎軸內。
Note: Magnets are not
included in the kit.
Magnets are usually provided
along with Governor & sensor kit.
磁鐵附在電子定數器&感應器包內。
