GAUI NX4 - Servo Assembly

GAUI
TAI SHIH HOBBY CORPORATION
GAUI
TAI SHIH HOBBY CORPORATION
Servo assembly-1
Servo assembly-2
ժ݉ᐡಣ၇.2
ժ݉ᐡಣ၇.3
18
M2.6x10
M2.6x10
M2.6x10
M2.6x10
M2.6x10
M2.6x10
M2.6x10
M2.6x10
M2x10
N2x4L
Depending on differences in servo
used, please, use different length
aluminum collar to adjust the
servo arm link.
።ᐍңᎠ৉;
Aluminum collar for adjustment
P2x3.5x1.5
P2x3.5x2.5
P2x3.5x3.5
ӱᔗϛӤժ݉ᐡ೤፝ٻңᎠ৉Ȃ
።ᐍժ݉ᐡഀఝ࣐࠮ޣȄ
M2.6x10.....................x8
M2x10........................x2
N2x4L........................x2
18mm
41.5mm
23.5mm
11.6mm
M2.6x10
M2.6x10
M2.6x10
M2.6x10
Depending on differences in servo
used, please, use different length
aluminum collar to adjust the
servo arm link.
።ᐍңᎠ৉;
Aluminum collar for adjustment
P2x3.5x1.5
P2x3.5x2.5
P2x3.5x3.5
ӱᔗϛӤժ݉ᐡ೤፝ٻңᎠ৉Ȃ
።ᐍժ݉ᐡഀఝ࣐࠮ޣȄ
M2x10
N2x4L
M2.6x10.....................x4
M2x10........................x1
N2x4L........................x1
41.5mm
23.5mm
11.6mm
Note: Linkage rods are aligned
perfectly vertically.
調整伺服機座至拉桿成垂直。
