GAUI NX4 - Tail Control Adapter Mount; Servo Mount Assembly

GAUI
TAI SHIH HOBBY CORPORATION
GAUI
TAI SHIH HOBBY CORPORATION
Tail control adapter mount
Servo mount assembly
׏ಹᙾ௦Ꮳಣ၇
ժ݉ᐡ৵ಣ၇
3
M3x6
M3x6
W3.1x4.6x0.6
B3x6x2.5
B3x6x2.5
M3x12
M3x6
M3x6
M3x6
M3x6
M3x7
M3x7
M3x7
M3x7
M3x6........................x2
M3x12......................x1
Bearing 3x6x2.5.......x2
M3x6........................x4
Washer 3.1x4.6x0.6 x1
M2x4.8x6.5..............x2
Stainless ball M2x4.8x6.5
ϛ㠅ᓂ౩ᓟ
M3x7........................x4
Servo mount
ժ݉ᐡ৵
ᖴ๜ְሰαЦྥᏙ
All screws on side plates should
be applied with thread lock.
ᖴ๜ְሰαЦྥᏙ
All screws on side plates should
be applied with thread lock.
