GAUI NX4 - Engine Mount (Right)

GAUI
TAI SHIH HOBBY CORPORATION
GAUI
TAI SHIH HOBBY CORPORATION
Engine mount (right)
fuel tank assembly
ЖᔞѢڿۢݗಣ၇
ݷጒಣ၇
16
M3x28
M3x28
ᖴ๜ჭб
஡Q/26ಣ၇ԂޠݷጒဋΤᐡٙٯԄίშಣ၇Ȅ
Countersunk Washer
(17.5mm)
Cylinder frame post
༬Ꭰ࢙
ሰႲߞ࡚ഀ௦Վ௷ᆔ
෶Ꭻჭ
(17.5mm)
Cylinder frame post
Install the assembled fuel tank into heli frame.
Leave enough fuel line length to connect to the muffler.
༬Ꭰ࢙
(23.5mm)
Cylinder frame post
༬Ꭰ࢙
M3x28.......................x2
Ø5.5mm
ᖴ๜ְሰαЦྥᏙ
All screws on side plates should
be applied with thread lock.
Rubber damper
