Tail pushrod assembly
Tail transmission assembly
ࡤܝఝಣ၇
༉ᖃܜಣ၇
26
1.Insert the tail boom, make
sure the gear mesh is
approximately 0.1mm.
2.Tighten M3x18 screws to lock
tail boom in place (P.2, M3x18
was not tightened).
0.1mm
2/༉ᆔဋΤᐡٙٯጃᇰ
!!Ꮠራ1/2nnȄ
3/ᚈᆨQ/3ޠN4y29ᖴ
M3x18
ԛαܝఝࡤ፝ጃᇰᙾ௦৵ᇅժ݉ᐡ࣐ޣЬ҂Ȅ
When installing the pushrod, please ensure that
the pushrod adapter and servo are leveled.
Insert the tail push rod through the guides then adjust
the linkages to achieve proper length.
ࡤܝఝΤᆔַ৵Іܝఝ৵ȂପӬίშ።ᐍܝఝߞ࡚Ȅ
