GAUI NX4 - Tail Boom Support Assembly; Canopy Assembly

GAUI
TAI SHIH HOBBY CORPORATION
GAUI
TAI SHIH HOBBY CORPORATION
Tail boom support assembly
Canopy assembly
׏Мእఝಣ၇
ᑼဌಣ၇
27
Assemble the tail boom brace.
஡ڎММእఝᚈαᐡٙȄ
M3x12
P3x6x4.2
Ø
3x8
፝Ӓ஡ᑼဌԛΤᑼဌћᄿϲȄ
ᖴ๜ְሰαЦྥᏙ
All screws should be applied with
thread lock.
M3x14.......................x2
P3x6x4......................x2
Ø3x8.........................x3
Insert canopy into canopy clip.
Ø
3x8
