Clutch assembly
Engine cover assembly
ᚕӬᏣಣ၇
Жᔞဌಣ၇
7
M3x6 2pcs
One way bearing B10x14x12
Clutch
M2.6x10 2pcs
Hex post (23.5mm)
൑ӪໆܜC21y25y23
ᚕӬᏣ
ϳِᎠ࢙(23.5mm)
Hex post (23.5mm)
ϳِᎠ࢙(23.5mm)
M3x6........................x2
M2.6x10...................x2
One Way Bearing
B10x14x12.............x1
ᖴ๜ְሰαЦྥᏙ
All screws on side plates should
be applied with thread lock.
