GAUI NX4 - Fuel Line Assembly; Engine Mount (Left)

GAUI
TAI SHIH HOBBY CORPORATION
GAUI
TAI SHIH HOBBY CORPORATION
Fuel line assembly
Engine mount (left)
ᐾݷᆔಣ၇
Жᔞѿڿۢݗಣ၇
17
M3x28
M3x28
஡ݷᆔඩΤЖᔞᐾݨΤπȄ
༬Ꭰ࢙(17.5mm)
෶Ꭻჭ
Cylinder frame post
Rubber damper
Connect fuel line from fuel tank
to the engine fuel intake connector.
ᖴ๜ჭб
Countersunk Washer
M3x28.......................x2
ᖴ๜ְሰαЦྥᏙ
All screws on side plates should
be applied with thread lock.
