GAUI NX4 - Main Rotor Assembly; Main Shaft Collar

GAUI
TAI SHIH HOBBY CORPORATION
GAUI
TAI SHIH HOBBY CORPORATION
Main Shaft collar
Main Rotor assembly
лໆᎉᔭಣ၇
лఌᖏᓟಣ၇
14
M3x3
Mast collar
Lift main shaft before installing the
mast collar on the main mast, then
tighten the mast collar securely.
M3x3
M3x16
N3X5.5L
ಣ၇лໆᎉᔭ፝Ӓ஡лໆαණՎۼȂ
ӶᚈߤN4y4ᖴ๜Ȃ৉ΤΫԆዻᖃԚȄ
лໆᎉᐁ
M3x3........................x2
M3x16......................x1
N3x5.5L...................x1
ᖴ๜ְሰαЦྥᏙ
All screws should be applied with
thread lock.
