Magnapunch 2.0 – Installation and Operating Instructions
Ca R i n G f o R t h e Ma G n a p U n C h 2.0
The primary maintenance required by the operator
is to periodically empty the Chip Drawer and to keep
the work area clean and free of paper debris and
dust. The Edge Sensors within the Die Sets may
need to be replaced occasionally.
die se t Ma i n t e n a n C e
The Edge Sensor feature referred to in “Edge
Sensor” requires sensor flags to be installed in the
Die Sets. If the machine begins to not sense the
media being inserted in the throat, the sensor flags
may need to be changed. Please follow the steps
below to replace the sensors.
To replace Die Set Edge Detection sensor flags:
Grab the die set handle by placing your palm on 1.
the front and wrapping your fingers behind the
handle. Pull the Die Set out of the Magnapunch
2.0 and place it face down on a sturdy surface.
Using a Phillips screw driver, remove the screws 2.
holding the two sensor flags in place.
Pull out the old sensor flags and replace with 3.
new ones.
Reinsert the screws and tighten4.
Replace the Die Set in the Magnapunch 2.0.5.
WARNINGS:
Do not attempt to service or repair the •
Magnapunch 2.0.
Do not open the Magnapunch 2.0. There are no •
user serviceable parts inside.
Refer service to qualified service personnel.•
Failure to observe these warnings could result in
severe personal injury or death.
7. op e R a t o R Ma i n t e n a n C e
Cl e a n i n G t h e Ma G n a p U n C h 2.0
Clean only the exterior of the Magnapunch
2.0. A soft, damp cloth may be used to wipe
the Magnapunch 2.0’s exterior, but do not
use detergents or solvents as damage to the
Magnapunch 2.0 may occur.
