Expert Pro User Manual
General Information
1-5
1.4.4 The Left-hand Side of Expert Pro (Figure 1-4)
1.4.5 The Right-hand Side of Expert Pro (Figure 1-5)
Fuse – 3 Amp.
AC Power Connector
Power Switch – On when switches to [I]; Off to [O]
Figure 1-4
Serial Interface Connector (RS232C)
used to connect the cutting plotter to a
computer through a serial interface cable.
Figure 1-5
USB Connector
used to connect the cutting plotter to a
computer through a USB cable.
