GCC Technologies EP-60 - 3.4 Menu Items

Expert Pro User Manual
The Control Panel 3-5
3.4 Menu Items
Below describes the functions of menu items
Menu or Key
Function Setting Default
--- Media sizing ---
Roll To measure media width. Maximum Tracking 150
meters
Edge To measure media width and pull the media back till
the front
paper sensor open.
Maximum Tracking 150
meters
Single To measure media width and length. Maximum Tracking 10
meters
--- POWER ---
To indicate the power status.
[ Arrow Keys ]
1. To move the tool carriage position on X or Y axis.
2. To select functions or change values of settings.
[ ENTER ]
1. The displayed parameters will be saved automatically.
2. To set a new origin at the present tool carriage position.
In “offline” mode, moving the tool carriage to desired
position by [Arrow Keys], then press [ENTER] key to set a
new origin. While moving with the parameters of XY-axes
displayed, press [MISC] key will enable fine-tune
movement; press [MISC] key again to disable the function.
[ PAUSE/RESUME ]
To temporarily halt the cutting process.
To resume the process by press [Pause/Resume] key again.
[ ONLINE/OFFLINE ]
1. To switch between online mode and offline mode.
2. To stop the cutting job or abort the change of setting.
Once press this key, the cutting job will be terminated
immediately and cannot be resumed.
[ OFFSET ]
To set or modify the distance between the blade tip and the
center axis.
0.000~1.000mm 0.275mm
[ FORCE ]
To set or modify the value of tool force. 5~400gram;
5
gram/per step
80 gram
[ SPEED ]
Speed To set or modify tool speed at horizontal moving. 3~60cm/sec;
3cm/sec per step
51cm/sec
Up Speed To set or modify tool speed at vertical moving. 3~60cm/sec;
3cm/sec per step
51cm/sec
Cutting Quality
To set or modify cutting quality.
[Slower speeds / higher quality - Faster speeds / lower quality]
The Set Cutting Quality Page allows you to adjust and balance
vector mode’s quality and speed settings based on your
specific job. Draft Mode offers the highest output speed,
sacrificing quality. Whereas Quality Mode offers the highest
Draft, Normal, Fair,
Fine
Normal
