Expert Pro User Manual
Installation 2-13
1. Install Blade. (Figure 2-13)
2. Push the blade to the bottom of the blade holder. (Figure 2-14)
3. Adjust the blade tip to suitable length by rotating “Blade tip adjustment screw”
clockwise or counterclockwise. (Figure 2-15)
Tips:
“The proper length” means
the blade length is about
0.1mm more than film’s
thickness. For example, if
the thickness of film is
0.5mm, then the blade
length is properly adjusted
to 0.6mm and it can
completely cut through the
film layer without cutting
though the paper backing.
Figure 2-11
Figure 2-13
Figure 2-14
Figure 2-15
