Expert Pro User Manual
Operation 4-2
Figure 4-2
Push the lever downward to lower down the pinch rollers.
Turn on the power; the machine will be initialized. Then follow the instruction of LCM to measure
the size of the media.
Note:
Move the pinch roller by applying force at the rear portion of the pinch roller support. Do not
move it by holding its front rubber roller.
Figure 4-3 correct way to move pinch rollers
White Marks
