Expert Pro User Manual
Operation 4-4
Option B
Insert the two roll holders into the roll media support set, and then place the roll media directly
between the two roll holders. (Figure 4-7)
3. Loading the media on the platen. After loading the roll media, flatten the media on the platen
and hold the front edge of the roll media firmly (Figure 4-8).
Figure 4-7
(The Puma model is used in the pictures for illustration.)
Figure 4-8
