Expert Pro User Manual
Puma II Plus Specification A-1
Expert Pro Specification
Model Name/No. EP-60 EP-132S
Operational Method Roller-Type
Max. Cutting Width 600mm(23.6in) 1300mm(51.18in)
Max. Cutting Length
50m(164ft)
Max. Media Loading Width 719mm(28.3in) 1470mm(57.87in)
Min. Media Loading Width 50mm(2.76in)
Acceptable Material Thickness 0.8mm (0.03in)
Number of Pinch Rollers 2 4
Motor Drive DC Servo Control
Cutting Force 400 g
Max. Cutting Speed Up to 600 mm /sec (23.62 ips)
Offset 0~1.0 mm (with an increase of 0.025 mm)
Mechanical Resolution 0.009 mm (0.00035in)
Software Resolution 0.025 mm (0.00098in)
Distance Accuracy ±0.254 mm or ±0.1% of move, whichever is greater
Repeatability ±0.1mm up to 5 meters (* certified media)
Memory Buffer 4MB
Interfaces USB 2.0 (Full Speed) and Serial (RS-232C)
Type of Command HP-GL, HP-GL/2
Control Panel LCD (20 digits x 2 lines), 14 Keys, 1 Power LED
Dimension (HxWxD) mm
220x 879x258mm
8.67 x34.61x10.16in
1065 x 1632 x 620mm (including stand)
41.93 x62.25x24.41in
Net Weight 13kg / 28.6lb 53 kg / 116.4 lb
Stand Optional Standard
Power Supply AC 100-240V, 50~60 Hz (auto switching)
Power Consumption Max.110watts
Environment Temperature 15 ~℃ 30℃ / 60 ~℉ 86℉ (operating)
Environment Humidity 25%~ 75% relative humidity (operating)
Compatible with Windows 2000/ XP/ Vista/ 7/ 8 and MAC OS X 10.4-10.7.
The specification and data sheet may vary with different materials used. In order to obtain
the best output quality, please maintain the machine regularly and properly.
GCC reserves the right to change the specifications at any time without notice.
The above listed specification values are effective only when operated with media certified
by GCC.
