Select Focus Lens Page
The Select Focus Lens Page allows you to modify the lens setting after you have changed to a
different focal lens. Remember to save your settings after you have made the proper changes.
Now by pressing the Auto Focus button, the LaserPro C180 will auto focus properly using the new
lens. The LaserPro C180’s default setting is <2.0">
• Lens: 1.5" / 2.0"
Select Focus Lens Page
Relevant Buttons Function
/
Directional No Action
/
Directional Scrolls through options
Enter Saves the indicated option
Menu
Go to Menu Page
A/F
Initiate the auto focus function
A/F ▲ / ▼ Directional
Manually adjust the height of the work table (Z-axis)
Start / Pause Go to Main Work page
Stop Go to Main Work page
Back Go to previous screen
Light Turn Light On/Off
Carriage / Work Table
Adjustment Page
Main Work Page
Menu Page
Press Menu
Navigating to this page:
Machine Setting Page
Select <Select
Focus Lens>
from the menu
Select Focus Lens Page
Select <Machine
Setting> from the
menu
To Next Page
