Tune Auto Focus Page
The Tune Auto Focus Page allows you to manually adjust the default auto focus distance / vertical height
of the worktable (Z-axis) for when the Auto Focus button is pushed.
Tune Auto Focus Page
Relevant Buttons Function
/
Directional Move table up and down
/
Directional No action
Enter Saves the current focal distance
Menu
Go to Menu Page
A/F
Initiate the auto focus function
A/F ▲ / ▼ Directional
Manually adjust the height of the work table (Z-axis)
Start / Pause Go to Main Work page
Stop Go to Main Work page
Back Go to previous screen
Light Turn Light On/Off
Carriage / Work Table
Adjustment Page
Main Work Page
Menu Page
Press Menu
Navigating to this page:
Machine Setting Page
Select <Turn Auto
Focus> from the
menu
Tune Auto Focus Page
Select <Machine
Setting> from the
menu
To Next Page
