NOTE
The maximum diameter and length of the to-be-engraved object is as follows:
˙
Small conical xture: 50 mm and 250 mm.
˙
Big conical xture: 127 mm and 250 mm.
˙
Maximum weight should not exceed 5 kg.
Exchanging the conical xtures on the rotary attachment:
A. Remove the 2 screws shown in the picture below.
B. Detach the circular cylindrical cone by moving it in the direction of the arrow as
shown below.
Remove these screws
