Puma II User’s Guide 2-22
If the square appears BB or CC layout, adjust the OFFSET setting (please refer to
paragraph SW1-3 OFFSET SETTING; Please also refer to the paragraph “About the
tool ” at the beginning of the book to learn the definition of offset.)
Note: The new origin will be set at the position of tool carriage after cutting test.
