Chapter 4 Virtual LCD
4.1 Installation
1. Start Windows 98, ME, 2000, or XP.
2. Insert “Installation CD” into your CD-ROM.
3. Click on “installation of VLCD”
4. Follow the appropriate screen prompts to install the VLCD
TM
program.
4.2 Before using VLCD
TM
This utility acts as a virtual display to assist you when checking the configurations in
your cutting plotter.
To run this utility, simply execute it under Windows. Before starting the detection,
make sure:
1. The cutting plotter is at the ON LINE status.
2. There is media in the machine.
4.3 Functions of VLCD
TM
Choose the right port whenever you use the VLCD (Figure 4.3.1). If you are
using the USB cable, choose USB0 from the pull down menu. If you are using
a Serial cable, choose either COM1 or COM2. Make sure no other devices are
occupying the port that you are going to use.
Puma II User’s Manual 4-1
