3. REMOVING THE EXISTING COMPONENTS OF THE SX-2001/ SA-2100
May 18, 2016
11
HFR UPGRADE MANUAL
FOR SX-2001/SA-2100(A/T) TO SX-000(A/T)R
DIGITAL CINEMA SERVER WITH
INTEGRATED MEDIA BLOCK
3.3 Detach the Flat Cable
1. Detach the pin head of Flat cable from the DCI side as indicated in Figure 4.
3.4 Un-install the DCI Card
1. Un-install the DCI card by un-securing the screw.
Figure 4 Detach the flat cable
Figure 5 Un-install the DCI card
