GE Carestation 650 A1 - Auxiliary O2 Flowmeter (Optional); Auxiliary O2+Air (Optional)

Auxiliary O2 flowmeter (optional)
The auxiliary O2 port is available to provide supplemental oxygen to
patients undergoing surgical procedures.
2
1
AC.24.136
1. Auxiliary O2 outlet
2. Auxiliary O2 flow control
Figure 8-7 • Auxiliary O2 flowmeter
Auxiliary O2+Air (optional)
The optional auxiliary O2+Air port provides supplemental O2 or a
mixture of O2 and Air to patients undergoing surgical procedures.
1
2
AC.24.137
1. Auxiliary O2+Air switch
2. Auxiliary O2+Air outlet
Figure 8-8 • Auxiliary O2+Air
Carestation
™
620/650/650c (A1)
8-20 2076152-001
