6. Audio Pause key Stops audio for 120 seconds for any active, eligible high and medium priority alarms.
Prevents audio (audio off) for 90 seconds when no medium or high priority alarms are
active. Allows the operator to acknowledge any non-active medium or high priority latched
alarms.
Figure 2-12 • Display controls
Touch points
AC.24.050
21
3
4
5
6
1. Wave fields 4. Digit fields
2. Measured values 5. Ventilator quick keys
3. Function keys 6. Split screen values
Figure 2-13 • Normal/Full screen view with shaded touch point areas
Measured value touch points
Touching measured values provides access to the Alarm Setup
menu and alarm limits.
